## 1. Why This System Exists
A multi-tenant notification hub that unifies SMS, email, WhatsApp,
Slack, push, and Telegram delivery through a single API.

## 4. Value Creation Points
- Unified API across 6+ channels (integration overhead reduced)
- Template hydration (personalisation without code changes)
- Multi-provider per channel (vendor flexibility)
- Delivery analytics (PLANNED — drives platform stickiness)

## 7. Business Rules & Constraints
- Multi-tenant: organisation isolation on all data paths
- Provider credentials stored encrypted (KeyTools)
- SQS-based async delivery (Lambda consumer)
- Current statuses: SENT, ERRORED — no post-delivery tracking

## 9. Explicit Non-Goals
- Real-time analytics dashboard (future phase)
- Provider-side configuration management

10 sections. Generated from the codebase, not a template.

@prd — Generated output

# PRD: Engagement Analytics
Epic ID: EN-ANALYTICS

## Goal
Capture post-delivery engagement events (open, click, bounce)
from SendGrid, Twilio, and Firebase via webhooks, normalized
into a common status model for cross-channel analytics.

## Success Metrics
| Metric              | Current        | Target              |
|---------------------|----------------|---------------------|
| Delivery visibility | 0% (SENT only) | 100% tracked        |
| Time to engagement  | N/A            | <30s from provider  |
| Duplicate handling  | N/A            | Zero duplicate rows |

## Explicitly Out of Scope
- Real-time engagement dashboard UI (separate epic)
- Engagement-based routing decisions (future)
- Provider webhook retry configuration (use defaults)

Business language. Measurable metrics. Explicit scope boundaries.

@hld — Generated output

## Module Responsibility Matrix
| Module                | New Responsibility                         |
|-----------------------|--------------------------------------------|
| server (Express)      | + webhook endpoints (signature-verified)   |
| NEW: WebhookProcessor | Parse, verify, normalize, persist          |

## API Contracts
POST /webhooks/sendgrid  — signature verified via header
POST /webhooks/twilio    — Twilio request signing verified
Response: always 200 { received: true }  (prevent retry storms)

## Schema Changes
notification_transactions:
  + engagementEvents: [{ status, timestamp, provider, rawEventId }]
  + currentEngagementStatus: DELIVERED|OPENED|CLICKED|BOUNCED
  + index on { notificationId, rawEventId } for idempotency

Module boundaries. API contracts with error cases. Mermaid flows. Story index with estimates.

@tech-analysis — Story output

# Story WH-1: Webhook Route Scaffolding + Signature Verification
Epic: EN-ANALYTICS | Service: server | Estimate: 3 SP

## HLD Reference (embedded — developer never re-reads the HLD)
POST /webhooks/sendgrid — X-Twilio-Email-Event-Webhook-Signature
POST /webhooks/twilio   — X-Twilio-Signature
Response: 200 { received: true } always

## Acceptance Criteria
- [ ] Three webhook endpoints respond 200 for valid payloads
- [ ] Invalid signature → 200 + log warning + discard
- [ ] Endpoints bypass JWT auth (public, provider-initiated)
- [ ] Delegates to provider-specific parser via DI
- [ ] Request body limited to 1MB

## Code References
- Similar: src/server/controllers/NotificationController.ts (TSOA)
- Crypto:  src/server/utils/crypto.ts (HMAC base)
- DI:      src/server/container.ts (tsyringe)

4 stories, 11 SP total. No cross-module blockers. E2E + integration tests generated alongside.

@plan-mode — Phase 1: Safety Net

## Phase 1: Characterization Safety Net (no production changes)

Files: src/server/middleware/authenticate.ts
Tests: tests/server/middleware/authenticate.test.ts (new)

Webhook routes will bypass JWT auth. Confirm existing
authenticated routes remain protected after adding
unauthenticated webhook routes.

Characterization coverage to lock in:
- /api/notifications without JWT → still returns 401
- /api/organisation without JWT → still returns 401
- Valid JWT → org context correctly attached

Phase 1 never touches production code. Run these tests green, then proceed.

@plan-mode — Phase 2: Build

## Phase 2: Webhook Endpoints + Signature Verification
Files: src/server/controllers/WebhookController.ts (new)
       src/server/middleware/verifyWebhookSignature.ts (new)
Tests: tests/server/webhooks/signatureVerification.test.ts (new)

@Route("webhooks")
export class WebhookController extends Controller {
  @Post("sendgrid")
  @Middlewares(verifySendGridSignature)
  async handleSendGrid(@Body() events: SendGridEvent[]) {
    await this.processor.process('sendgrid', events)
    return { received: true }
  }
}

Test scenarios:
- Valid signature → reaches processor
- Invalid signature → 200, discarded
- Body >1MB → 413 rejected

@review-mode — Elaborate

## Why This Matters
Provider webhooks don't retry indefinitely:
- SendGrid: 3 days, then gives up
- Twilio:   24 hours
- Firebase: no retries

If DB is down and you return 200, those events are gone.

## Before:
try { await processor.process(events) }
catch (err) { logger.error(err) }
return { received: true }

## After:
try { await processor.process(events) }
catch (err) {
  await dlq.enqueue({ provider, events, error: err.message })
  logger.error('Queued to DLQ', err)
}
return { received: true }

Engineer sees the business risk, then decides: Go Next or Re-visit same file.
